1.   Turn on power.

2.   To adjust the height according to the thickness of the  puzzle
       material, loosen the setscrew at the rear, adjust the height
       with the adjustment handle at the upper part, and then screw
       up the setscrew. Turning the adjustment handle to the right
       side reduces the clearance between rollers and turning to the
       left increases it.

3.   Prepare the puzzle material first, remove a part of the special
       release paper on the surface of sticker as shown in the right
       figure, put a part of the photo to make the puzzle accurately,
       and then, remove the release paper completely from the
       adhesive sticker and press the photo hard with hand.

4.   Lift the rear cover of the puzzle blade and put the puzzle
       material with the photo to be cut and bottom plate together to
       align the cutting line.

5.   Put up the cover to fix the photo and puzzle blade upside down.

6.   Press the foot switch to operate the machine and push the
       puzzle blade on the inward side of the roller slowly.

7.   Puzzle is finished as the puzzle blade passes through the roller.
      Turn the puzzle blade passed through roller upside down and
       then open the cover to take out the finished puzzle.

8.   Pack the finished puzzle.
