paper users with high quality standards, and lower volume demand.
cost for a lower volume business. The Brooke
Cut One cutters are a cost effective way to get
into the automation game.
CUT ONE'S cutting system will lower your costs
of production and do away with awkward print
roll handling. Load your roll of prints. Fast
manual advance. Press a button or foot pedal
to actuate. Cut prints and slugs simultaneously
with the optional double cut blade assembly.
CUT ONE cutters are made for roll-to-print
cutting.
Cut One-12 handles 2 3/4 inch thru 12 inch wide, and Cut One-20 handles from 3 1/2 inch thru 20 inch wide.
Maximum Capacity 575-foot paper rolls. Already have a roll cutter? Cut One is a sensible backup cutter for
overflow work, while automatic cutters are occupied.
CUT ONE'S are upgradeable to fully automatic BP-1200 (12-inch) and BP-2000 (20-inch) high speed
production cutters. You won't lose your initial investment as your volume increases.
In Fact, over half of previous purchasers have upgraded Cut One's to automatic cutters. If the Cut One
looks similar to the BP-1200, it's for good reason. Both are built on the same chassis as the BP-high speed
automatic cutters.
| CUT ONE-12 |
CUT ONE-20 |
|
| Paper Capacity |
275" thru 12"X 575' 6.99 cm thru 30.48 cm X 175 m |
3.5" thru 20" X 575' 6.99 cm thru 30.48 cm X 175 m |
| Foot Print (Dimensions) width depth height |
40" (101.6 cm) 22" (59.9cm) 14" (35.6 cm) |
40" (101.6 cm) 30" (76.2 cm) 14" (35.6 cm) |
| Weight (Approximate) |
50 lbs. (22.7kg) |
82 lbs. (37.7kg) |
| Options |
Double Cut Blade Assembly |
|
| Electrical Requirements |
110/120 VAC, 50/60 Hz, 200 Watts |
110/120 VAC, 50/60 Hz, 200 Watts |
